By KINUGAWA
Kinugawa Turbo TF06-GTX3071R for Subaru FA24 FA24DIT VB WRX 2022+
$1,279.00 - $1,579.00
Shipping calculated at checkout.
Regular price
$1,279.00
Regular price
$1,279.00
Sale price
$1,279.00
Unit price
per
Couldn't load pickup availability
Availability:
Low stock: 4 left
SKU:
301-02049-354
Tags:
Collections:
Regular price
$1,279.00
Regular price
$1,279.00
Sale price
$1,279.00
Description
- We're super excited to share our new 600+ Upgrade Subaru WRX '22+ Turbo Kit, made just for the VB Chassis WRX! It's super easy to install with a perfect OEM fit—no modifications needed! If you're a performance enthusiast, you'll love its quick spool times, durability, and awesome boost response. It's perfect for hitting the streets or hitting the track—let's take your ride to the next level! coupled to the 9.5 cm2 turbine section. This bolt-on solution produces a great balance of spool and power. This turbo comes with an oil line and gasket set, giving you everything you need to bolt it straight onto your car. The factory oil drain sump will be kept and reused.
Application
- Subaru FA24 WRX 2022+
- Subaru Legacy Outback
- Subaru Ascent 2019~2023
- Subaru Legacy Outback
- Subaru Ascent 2019~2023
The maximum power stated for each turbocharger has been calculated based strictly on the choke flow of the compressor map (total turbo capability), which represents the potential flywheel power. Performance results of this product are highly dependent upon your vehicle’s modifications and tuning/calibration
CHRA Size
- TF06-GTX3071R
Wheels Spec
- Compressor wheel: 54 / 71.4 mm (Billet 11+0 Point Milling)
Compressor Housing
- Bolt-on stock type
Turbine Housing
- Nozzle area: 9.5cm (AR .69)
- Inlet: Subaru FA24 twin scroll
- Outlet: Subaru FA24 3-bolt
- Wastegate: internal gated
Bearing Type
- Bolt-on stock type
Turbine Housing
- Nozzle area: 9.5cm (AR .69)
- Inlet: Subaru FA24 twin scroll
- Outlet: Subaru FA24 3-bolt
- Wastegate: internal gated
Bearing Type
- 2 Options: Dual Ceramic Ball Bearing or Journal Bearing with 360-degree thrust bearing
Cooling Type
- Oil and Water Cooling System
The Set Includes
- 1 x Turbocharger (without actuator)
- 1 x Turbocharger (without actuator)
- 1 x Oil supply set
- 1 x water supply and return pipe set
- 1 x Return Oil Pipeline
- 1 x turbine inlet and outlet gasket
- 5 x stud kits
Situation
- Brand New
- Full balance from SCHENK MBRS 110 Germany
Provider
- Kinugawa Turbo Systems
Warranty
- For complete peace of mind, Kinugawa Turbo Systems offers a KINUGAWA TROUBLE-FREE WARRANTY for 1 year from the purchase date to the original purchaser. If, for any reason, your turbocharger/s fails or has an issue, you can return it to us for a free overhaul and recondition or replacement depending on availability or the turbo problem. You can be assured that KINUGAWA will cover you no matter the issue.
